BenQ MX808STH - Interactive Classroom Projector with Short Throw, XGA

The BenQ MX808STH is an interactive short throw projector designed for dynamic classroom environments. With a short throw ratio of 0.61, it provides large, clear images while minimizing shadows and glare, making it ideal for engaging and collaborative teaching. Featuring 3,600 ANSI lumens brightness and XGA resolution (1024x768), this projector ensures sharp, vivid presentations even in well-lit rooms. Equipped with PointWrite™ technology, it turns any surface into an interactive whiteboard, supporting multi-touch and multi-screen drawing. The MX808STH also includes SmartEco™ technology for energy efficiency and long-lasting performance, making it a versatile tool for modern educational settings.

Key Features:

• Short Throw Ratio: 0.61 for large, clear images from a short distance.
• High Brightness: 3,600 ANSI lumens for bright, vivid projections even in well-lit classrooms.
• XGA Resolution: 1024x768 resolution for detailed and sharp images.
• PointWrite™ Technology: Transforms any surface into an interactive whiteboard with multi-touch support and easy integration.
• SmartEco™ Technology: Extends lamp life up to 15,000 hours and reduces energy consumption by up to 70% with adaptive brightness control.
• Digital Shrink & Shift: Allows for convenient screen size adjustment through the OSD menu without physically moving the projector.
• BYOD Compatibility: QCast wireless dongle support for up to 4 participants to stream content simultaneously.

Specifications:

• Brightness: 3,600 ANSI Lumens
• Native Resolution: XGA (1024x768)
• Aspect Ratio: 4:3
• Contrast Ratio: 20,000:1
• Display Color: 30-bit (1.07 billion colors)
• Light Source: Lamp
• Light Source Life: Normal 6,000 hrs, ECO 10,000 hrs, SmartEco 10,000 hrs, LampSave 15,000 hrs
• Throw Ratio: 0.61
• Zoom Ratio: Fixed
• Lens: F/# = 2.56 ~ 2.68, f = 22 ~ 24.1 mm
• Projection Offset: 100%
• Keystone Adjustment: Auto Vertical ± 40 degrees
• Picture Modes: 3D, Bright, Infographic, Presentation, Spreadsheet, sRGB, User 1, User 2
• Resolution Support: VGA (640 x 480) to WUXGA_RB (1920 x 1200)
• Horizontal Frequency: 15K~102KHz
• Vertical Scan Rate: 23~120KHz

I/O Interfaces:

• PC in (D-sub 15pin): 1
• Monitor out (D-sub 15pin): 1
• Composite Video in (RCA): 1
• S-Video in (Mini DIN 4pin): 1
• HDMI in: 2 (HDMI-1 and HDMI-2, 1.4a/HDCP1.4)
• USB Type A: 1
• USB Type Mini B: 1
• RS232 in (DB-9pin): 1

Audio:

• Speaker: 10W
• Audio in (3.5mm Mini Jack): 1
• Audio out (3.5mm Mini Jack): 1

Environment:

• Operating Temperature: 0~40°C
• Power Supply: AC 100 to 240 V, 50/60 Hz
• Typical Power Consumption (110V): 260W
• Acoustic Noise: 34 dB (Typical), 29 dB (Eco)

Accessories:

• Remote Control: Included with Battery
• Power Cord: 1.8M (by region)
• VGA Cable: 1.5m (Standard)
• User Manual CD: Included
• 3D Glasses: Optional
• Quick Start Guide: Included
• Warranty Card: Included (by region)
• Universal Ceiling Mount: Optional

Dimensions & Weight:

• Dimensions (WxHxD): 296 x 120 x 221 mm
• Net Weight: 2.3 kg

Projection System:

• Projection System: DLP

Notes:

• The lamp contains mercury. Dispose of it according to local regulations.
• Lamp life may vary based on environmental conditions and usage. Specifications are subject to change without notice.

Transform your classroom with the BenQ MX808STH, offering advanced interactive features, high brightness, and versatile functionality for an enhanced teaching experience.
