MSI MAG 275UPD E14 - 27" 4K UHD Gaming Monitor

The MSI MAG 275UPD E14 27-inch 4K gaming monitor is engineered to deliver exceptional visual performance for competitive gaming and immersive entertainment. A premium IPS panel is combined with an innovative Dual Mode feature, allowing seamless switching between 3840 × 2160 UHD at 144Hz and 1920 × 1080 Full HD at 288Hz. Fast-paced esports titles can be enjoyed with ultra-high refresh rates, while cinematic games and creative content can be experienced with crisp 4K clarity. Designed for FPS, RPG, MMORPG, racing, and flight simulation games, a smooth and responsive gaming experience is consistently provided.

Advanced gaming technologies are integrated to enhance every session. AMD FreeSync™ Premium, HDR Ready, AI Navigator, and One-Click Dual Mode Switching are included to deliver fluid gameplay, simplified navigation, and vivid image quality. A wide color gamut covering 130% sRGB, 90% DCI-P3, and 84% Adobe RGB ensures vibrant, lifelike colors, while the anti-glare coating helps maintain visibility in different lighting environments. Flexible console compatibility, ergonomic adjustments, and multiple connectivity options make this monitor an excellent choice for both PC and console gamers.

Key Features

Dual Mode UHD 144Hz & FHD 288Hz

Two display modes are supported to match different gaming styles. Ultra-sharp 4K UHD at 144Hz is provided for detailed visuals, while Full HD at 288Hz delivers maximum responsiveness for competitive gaming.

AI Navigator with One-Click Switching

An intelligent AI Navigator and dedicated One-Click Switch allow display settings and Dual Mode configurations to be changed quickly and conveniently through the integrated 5-way joystick.

Fast IPS Gaming Performance

A 1ms MPRT response time and AMD FreeSync™ Premium technology help reduce motion blur, screen tearing, and stuttering for smooth gameplay during fast-action scenes.

Wide Color Gamut

Rich and accurate colors are reproduced with 130% sRGB, 90% DCI-P3, and 84% Adobe RGB color coverage, making games, videos, and creative content appear more realistic.

HDR Ready Support

Greater brightness and enhanced contrast are supported with HDR Ready, allowing compatible content to display improved depth and more detailed highlights.

Console Ready

The monitor is optimized for PlayStation 5 and Xbox Series X|S, with support for VRR, HDMI™ CEC, and multiple console resolutions and refresh rates for a smooth gaming experience.

Flexible Aspect Ratio Options

Multiple aspect ratio settings are available, including a 24.5-inch display mode, allowing gameplay to be customized based on personal preference or game type.

Ergonomic Design

Comfort is enhanced through comprehensive ergonomic adjustments, including height, tilt, swivel, and pivot, allowing the display position to be optimized for extended gaming sessions.

Specifications

Model: MSI MAG 275UPD E14

Series: MSI MAG (MSI Arsenal Gaming)

Panel Size: 27 inches

Active Display Area: 596.736 × 335.664 mm

Curvature: Flat

Panel Type: IPS

Resolution:

• Normal Mode: 3840 × 2160 (UHD)
• Dual Mode: 1920 × 1080 (FHD)

Pixel Pitch: 0.1554 × 0.1554 mm

Aspect Ratio: 16:9

Brightness:

• SDR: 250 cd/m²

Contrast Ratio: 1500:1 (Typical)

Dynamic Contrast Ratio (DCR): 100,000,000:1

Signal Frequency:

• UHD: 106.1–318.2 kHz (Horizontal) / 48–144Hz (Vertical)
• FHD: 106.1–318.2 kHz (Horizontal) / 48–288Hz (Vertical)

Variable Refresh Range:

• Normal Mode: 48–144Hz
• Dual Mode: 48–288Hz

Maximum Refresh Rate:

• UHD: 144Hz
• FHD: 288Hz

Response Time: 1ms MPRT

Adaptive Sync: AMD FreeSync™ Premium

HDR: HDR Ready

Video Inputs:

• 1 × DisplayPort 1.4a (HBR3)
• 2 × HDMI™ 2.1 (4K@144Hz)

Audio Output:

• 1 × Headphone-Out

Viewing Angles: 178° Horizontal / 178° Vertical

Color Gamut:

• Adobe RGB: 84%
• DCI-P3: 90%
• sRGB: 130% (CIE1976 Standard)

Surface Treatment: Anti-glare

Display Colors: 1.07 Billion (10-bit, 8-bit + FRC)

Speakers: 2 × 2W

Console Mode Features:

• 1080p: 60Hz / 120Hz
• 1440p: 60Hz / 120Hz
• 2160p: 60Hz / 120Hz
• HDMI™ CEC Supported
• VRR Supported for PS5 and Xbox

Power Type: Internal Power Board

Power Input: 100–240V, 50/60Hz

Ergonomic Adjustments:

• Tilt: -5° to 20°
• Swivel: -30° to 30°
• Pivot: -90° to 90°
• Height Adjustment: 0–130 mm

Kensington Lock: Yes

VESA Mount: 100 × 100 mm

Dimensions with Stand: 613.3 × 227.9 × 534.2 mm (24.1 × 8.9 × 21.1 inches)

Dimensions without Stand: 613.3 × 57.9 × 360.7 mm (24.1 × 2.2 × 14.3 inches)

Weight:

• Net: 6.1 kg (13.4 lbs)
• Gross: 8.7 kg (19.1 lbs)

Carton Dimensions: 810 × 150 × 462 mm (31.8 × 5.9 × 18.1 inches)

Included Accessories:

• 1 × DisplayPort Cable (1.4a)
• 1 × Power Cord (C13)
• 1 × Quick Guide

Supported Display Modes:

HDMI™

• UHD: 3840 × 2160 (Up to 144Hz)
• FHD Dual Mode: 1920 × 1080 (Up to 288Hz)

DisplayPort

• UHD: 3840 × 2160 (Up to 144Hz)
• FHD Dual Mode: 1920 × 1080 (Up to 288Hz)

Additional Features:

• AI Navigator
• One-Click Switch
• Dual Mode
• Aspect Ratio Options
• 5-Way Joystick Navigator
• HDMI™ CEC Support
• Picture-in-Picture (PIP)
• Picture-by-Picture (PBP)
• KVM: Not Supported

Conclusion

The MSI MAG 275UPD E14 is designed to provide exceptional versatility for modern gamers by combining 4K UHD visual clarity, 288Hz esports performance, and Dual Mode technology in a single display. A premium IPS panel, wide color coverage, AMD FreeSync™ Premium, HDR Ready support, ergonomic adjustments, and extensive connectivity are combined to deliver a gaming monitor that is well suited for competitive play, immersive AAA gaming, content creation, and next-generation console gaming.
