MSI PRO B760M-E DDR4 Motherboard for 14th/ 13th/ 12th Gen Intel Processor

The MSI PRO B760M-E DDR4 motherboard is engineered for performance and reliability, supporting Intel® 12th and 13th Generation Core™ processors. With a compact mATX form factor, this motherboard offers a robust set of features for both high-performance computing and everyday tasks. It supports up to 64GB of DDR4 memory with speeds up to 4800MHz (OC), and includes advanced connectivity options for both gaming and professional use.

The PRO B760M-E features an array of expansion slots, including a PCI-E x16 slot for high-performance graphics cards and an M.2 slot supporting PCIe 4.0 for fast storage solutions. It also provides comprehensive connectivity with multiple USB ports, HDMI and VGA outputs, and Realtek® Gigabit LAN for reliable network performance.

Key Features:

• Chipset: Intel B760, supporting 12th/13th Gen Intel® Core™ Processors, Pentium® Gold, and Celeron® Processors (LGA 1700 socket).
• Memory Support: 2 x DDR4 slots, supporting up to 64GB of memory with overclocking capabilities up to 4800MHz. Compatible with Dual-Channel mode and Intel® Extreme Memory Profile (XMP).
• Onboard Graphics: HDMI™ 1.4 and VGA outputs. Maximum resolution of 4K at 30Hz via HDMI™ and various resolutions up to 2048x1536 via VGA.
• Expansion Slots: 1 x PCI-E x16 slot (PCIe 4.0) and 1 x PCI-E x1 slot (PCIe 3.0).
• Storage Options: 1 x M.2 slot supporting PCIe 4.0 x4 and SATA modes, plus 4 x SATA 6G ports (note: SATA5 is unavailable when using M.2 SATA SSD in M2_1 slot).
• RAID Support: RAID 0, RAID 1, RAID 5, and RAID 10 for SATA storage devices.
• USB Ports: 4 x USB 2.0 (Rear), 4 x USB 2.0 (Front), 2 x USB 3.2 Gen1 Type A (Rear), 2 x USB 3.2 Gen1 Type A (Front).
• Networking: Realtek® RTL8111H Gigabit LAN.
• Audio: Realtek® ALC897 Codec with 7.1-Channel High Definition Audio.
• Internal I/O: Includes various connectors such as power connectors, CPU fan, system fans, front panel, RGB LED, TPM 2.0, and additional USB ports.
• LED Features: 4 x EZ Debug LED for troubleshooting.
• Back Panel Ports: HDMI™, VGA, Keyboard/Mouse, USB 3.2 Gen 1 (Type-A), LAN port, Audio Connectors, USB 2.0.
• Operating System Compatibility: Windows® 11 64-bit, Windows® 10 64-bit.
• Dimensions: mATX form factor, 200mm x 236.16mm.

Conclusion: The MSI PRO B760M-E DDR4 motherboard is a solid choice for users seeking a reliable and versatile platform for Intel® 12th and 13th Gen processors. With support for high-speed memory, advanced storage options, and comprehensive connectivity features, it caters to both gamers and professionals. The addition of troubleshooting LEDs and multiple USB ports ensures that the PRO B760M-E provides a convenient and efficient computing experience.
