The Synology DS923+ Quad-Bay NAS DiskStation offers advanced storage and data management for demanding environments. This high-performance NAS unit supports rapid file indexing, photo organization, and concurrent file transfers with up to 592 MB/s read and 562 MB/s write speeds. Engineered to handle a broad range of applications and user demands, it features up to 10GbE networking and dual M.2 NVMe slots for enhanced performance. The DS923+ integrates seamlessly with Synology Drive and Photos for streamlined file management and faster access.

Consolidate and expand your storage effortlessly with the DS923+. With 4 bays providing up to 54 TB of storage and the capability to expand to 126 TB with the DX517 expansion unit, this NAS is equipped to grow with your needs. It offers comprehensive backup and recovery solutions, including full system backups and point-in-time snapshots. Deploy a private cloud solution with ease, share files securely, and manage your data efficiently with Synology’s user-friendly interfaces.

Key Features:

• High-Speed Performance: Achieve up to 592 MB/s read and 562 MB/s write speeds, designed to handle demanding workloads and multiple users.
• Enhanced Networking: Equipped with 10GbE networking capabilities to support high-speed data transfer.
• Expansion Options: Four drive bays with support for up to 54 TB of internal storage, expandable to 126 TB with the DX517 unit.
• M.2 NVMe Slots: Two M.2 NVMe slots for additional caching and storage pool options.
• Private Cloud Solution: Easily deploy a personal cloud for secure file access and sharing across multiple devices.
• Advanced Backup and Recovery: Centralized backup management, full system backups, and point-in-time snapshots for robust data protection.
• Professional Photo Management: Tools for organizing, backing up, and sharing photos and videos securely.

Hardware Specifications:

• CPU Model: AMD Ryzen R1600

• CPU Quantity: 1

• CPU Architecture: 64-bit

• CPU Frequency: 2-core 2.6 GHz (base) / 3.1 GHz (turbo)

• Hardware Encryption Engine (AES-NI): Yes

• Memory:

  • System Memory: 4 GB DDR4 ECC SODIMM
  • Memory Module Pre-installed: 4 GB (4 GB x 1)
  • Total Memory Slots: 2
  • Maximum Memory Capacity: 32 GB (16 GB x 2)

• Storage:

  • Drive Bays: 4
  • Maximum Drive Bays with Expansion Unit: 9 (DX517 x 1)
  • M.2 Drive Slots: 2 (NVMe)
  • Compatible Drive Types: 3.5" SATA HDD, 2.5" SATA SSD, M.2 2280 NVMe SSD
  • Hot Swappable Drive: Yes (excluding M.2 SSD slots)

• External Ports:

  • RJ-45 1GbE LAN Port: 2 (Link Aggregation / Failover support)
  • USB 3.2 Gen 1 Port: 2
  • eSATA Port: 1

• PCIe Expansion: 1 x Gen3 x2 network upgrade slot

• Appearance:

  • Size (Height x Width x Depth): 166 mm x 199 mm x 223 mm
  • Weight: 2.24 kg

• Power Supply Unit / Adapter: 100 W

• AC Input Power Voltage: 100V to 240V AC

• Power Frequency: 50/60 Hz, Single Phase

• Power Consumption: 35.51 W (Access), 11.52 W (HDD Hibernation)

• Noise Level: 22.9 dB(A)

• Operating Temperature: 0°C to 40°C (32°F to 104°F)

• Storage Temperature: -20°C to 60°C (-5°F to 140°F)

• Relative Humidity: 5% to 95% RH

• Warranty: 3-year hardware warranty, extendable to 5 years with Extended Warranty Plus

Conclusion: The Synology DS923+ Quad-Bay NAS DiskStation provides a robust solution for data management and storage needs. With its high-speed performance, expandable storage capacity, and comprehensive backup features, it is well-suited for both personal and professional use. The DS923+ combines efficiency with flexibility, making it an excellent choice for managing, protecting, and accessing your data effectively.
