Rode RØDECaster Video - Video and Audio Production Console

The RØDECaster Video is designed to bring professional video switching and studio-quality audio mixing into one compact, powerful production console. Built for creators, podcasters, streamers, and broadcasters, it combines up to six simultaneous video inputs with pristine audio capture from Revolution Preamps™, dual wireless microphone receivers, and comprehensive APHEX® processing. With direct streaming capabilities via Ethernet or Wi-Fi, advanced scene building, and automated video switching, it enables the creation of polished, multi-camera productions with broadcast-level quality.

Featuring four HDMI inputs, two multifunction USB-C ports, and support for RØDE Series IV wireless systems, the RØDECaster Video ensures versatility for any content setup. Whether producing live talk shows, gaming streams, interviews, or corporate webinars, users can seamlessly integrate multiple video sources, overlays, transitions, and audio effects. Recording is supported directly to external USB storage with ISO tracks for post-production flexibility, while a high-resolution touchscreen and intuitive controls allow quick configuration. Built to meet the demands of modern content creation, this console offers a complete studio solution in a single device.

Key Features

• Support for six simultaneous video inputs and seven fully customizable scenes

• Four HDMI (1080p) inputs with auto frame rate conversion and two configurable HDMI outputs

• Two USB-C ports for webcams, RØDE USB microphones, and audio devices

• Studio-grade Neutrik® combo jacks with ultra-low-noise, high-gain Revolution Preamps™

• Integrated dual wireless receivers for RØDE Series IV microphones

• APHEX® audio processing with EQ, compressor, noise gate, high-pass filter, de-esser, Aural Exciter™, and Big Bottom™ effects

• Intelligent auto-switching based on audio inputs for hands-free production

• Direct streaming to YouTube Live, Twitch, Facebook Live, Twitter/X, or custom RTMP servers

• Recording to external USB storage with ISO video and multitrack audio options

• Advanced scene builder with chroma keying, media playback, overlays, and transitions

• High-resolution 2-inch touchscreen with rotary encoder for quick settings adjustments

Specifications

Audio
Analog Audio Inputs
2 combo jacks (microphone, line or instrument) with Revolution Preamps™

Wireless Audio Inputs
2 Series IV wireless receivers

Digital Audio Inputs
USB 1: 2-in/2-out or multichannel (20-in) output
USB 1 Chat (uses USB 1 port): 2-in/2-out with mix-minus
USB 2: 2-in/2-out with MFi support
USB 4 & 5: compatible with RØDE USB microphones and RØDECaster Pro II and Duo

Analog Audio Outputs
2 headphone outputs (1/4-inch)
2 balanced line outputs (1/4-inch, L/R)

Audio Mixer
20 possible audio sources (9 stereo channels simultaneously): combo 1 and 2 (can be combined for stereo), wireless 1 and 2, video clips, sounds, HDMI 1, 2, 3 and 4 (each can be split for two mono), Bluetooth, 3 USB audio interfaces (computers), 2 hosting USB audio devices (microphones)
12 Outputs with Custom Routing: live mix, headphone 1, headphone 2, recording, monitors, USB Main, USB Chat, USB 1, 2, 4 and 5, Bluetooth
Note: Each output can be independently configured with custom level, mute status and level offset settings for each of the 9 inputs

Audio Processing
APHEX® VoxLab™ Processing: per channel
Advanced APHEX® granular processing on each channel: Compressor, Equaliser (EQ), De-esser, Panning, Noise Gate, High-pass Filter, Aural Exciter™, Big Bottom™

Preamps
Frequency range: 20Hz – 20kHz
Input gain: up to 76dB
Equivalent Input Noise: -131.5dBV (A-weighted)

Streaming Sample Rate / Bit Depth
48kHz / 32-bit

Recording Sample Rate / Bit Depth
48kHz / 24-bit

Streaming, Recording and Software:
Direct Streaming
Real Time Messaging Protocol (RTMP/RTMPS) over Ethernet or Wi-Fi

Supported Platforms
YouTube Live, Twitch Live, Facebook Live, Twitter/X Live, Custom server

Network
Ethernet (10/100/1000 BaseT) and Wi-Fi 6 (2.4 and 5GHz) for streaming, configuration, remote control with computer and over-the-air updates

Storage Media
External USB mass storage device (exFAT format) for recordings

Video Recording
Program feed as H.264/AVC MP4 file with embedded AAC stereo mix

Isolated (ISO) Video Recording
6 video inputs and 1 Program feed as independent H.264/AVC files (up to 1080p30)

Audio Recording
Stereo mix WAV audio file

Multitrack Audio Recording
9 independent stereo WAV audio files

RØDE Central Companion Software

• Scene builder: advanced construction of scenes and remote control of device

• Auto-switching: configuration of automatic switching based on audio input

• Audio mixer: advanced configuration and control of audio sources, processing and routing

• Stream profiles: configuration for streaming settings and profiles

• Device configuration: advanced settings and customisations

Compatible Operating Systems
macOS 11 or later
Windows 10 Version 1803 or later
Windows 11

Switching
Total Number of Layers: 9 simultaneous in Preview and Program
Downstream Keyers: 2 (overlays and logo)
Chroma Keyers (Green and Blue): 2
Media Players: 2 simultaneous
Transitions: SMPTE wipes, dip and fade
True Preview: display complete scenes and overlays simultaneously in preview and program
Generated Borders: all scenes
Multiview: program and preview, live inputs, scene and media thumbnails, audio mixer and channel status, recording, network and storage status, run time, date and time information

Media Player
Expandable microSD card storage
Videos: MP4
Images: PNG, JPG
Audio: WAV

Bluetooth
5.3 (for stereo audio input or phone calls)

Power and Mechanical
Power Supply Requirements: USB-C PD 60W, 20V 3A
Weight (grams): 1257
Dimensions (millimetres): Length: 132.5 | Width: 305.9 | Height: 61.4

Video
Video Input Feeds
6 simultaneous

HDMI Inputs
4 type-A (HDMI 1.4b)

USB (UVC) Inputs
2 multi-function USB-C for UVC video

HDMI Outputs
2 configurable – preview, program, multiview

Video Input Frame Rates
1920x1080p: 23.97, 24, 25, 29.97, 30, 50, 59.94, 60
(HDMI only) 1920x1080i: 25, 29.97, 30

Video Output Frame Rates
1920x1080p: 24, 25, 30, 50, 60

Video Streaming Standards
1920x1080p: 23.97, 24, 25, 29.97, 30, 50, 59.94, 60

Video Engine Colour Space / Bit Depth
4:4:4 RGB / 8-bit

HDMI Input Colour Space / Bit Depth
4:4:4 RGB, 4:4:4 YUV, 4:2:2 YUV / 8, 10, 12-bit

USB Input Colour Space
4:2:2 YUV, 4:2:0 YUV (NV12)

HDMI Output Colour Space / Bit Depth
4:4:4 RGB, 4:4:4 YUV / 8-bit

USB Output Colour Space / Bit Depth
4:2:2 YUV / 8-bit

Format and Frame Rate Converters
On all HDMI and USB inputs

Conclusion
The RØDECaster Video combines professional-grade audio processing, advanced video switching, and direct streaming in a single, user-friendly unit. Designed for creators who demand reliability and versatility, it streamlines production workflows for live streaming, content creation, and recording with exceptional clarity and control. With robust connectivity options, multi-source integration, and intuitive scene management, it serves as a complete studio hub for high-quality, multi-camera productions.
