Tenda VDSL/ADSL Router V15 AX1500 2.4 & 5Ghz 4 Antennas Gigabit WIFI 6

The Tenda V15 AX1500 VDSL/ADSL modem router brings dual-band Wi‑Fi to your home with 2.4GHz and 5GHz operation, using Wi‑Fi 6 (IEEE 802.11ax) wireless standards. It is designed for VDSL/ADSL modem router working mode, supporting VDSL2 and ADSL standards listed for the router’s DSL connection features. With Gigabit Wi‑Fi 6 performance labeled as AX1500, it targets users who want fast, dual-band wireless access alongside wired connectivity. For networking and management, the V15 includes multiple wired interfaces and DSL connectivity options: 3 × 10/100/1000 RJ45 LAN ports, 1 × 10/100/1000 RJ45 LAN/WAN port, and 1 × RJ11 port, plus 1 × USB 2.0 port. It supports encryption and network features such as WPA, WPA2, WPA/WPA2, and WPA3, along with WPS, guest network, and MESH is listed as None. Management features include web-based configuration via HTTP, remote management, a command line interface, and web-based firmware upgrade, plus remote/diagnostic elements such as DHCP server functions and client list capabilities.
Key Features
• VDSL/ADSL Modem Router
• Wireless: AX1500
• 2.4GHz & 5GHz frequency
• IEEE 802.11b/g/n, IEEE 802.11ac, IEEE 802.11ax
• 4 × 5 dBi Antenna
• WPS
• Guest network
• Access Control
• MESH: None
• Security: None, WPA, WPA2, WPA/WPA2, WPA3
• Supports IPv4 and IPv6
• Management: Web Based Conguration(HTTP)
• Remote management
• command Line Interface
• SSL for TR-069
• SNMP v1/2c
• Web Based Firmware Upgrade
• Diagnostic Tools: DHCP
• DHCP Server
• Address Reservation
• Port Forwarding
• UPnP
• DMZ
• Dynamic DNS
• VPN: PPTP, L2TP, IPsec
Specifications
• Model: V15
• Reference: NETWORK L50
• Interfaces: 3 × 10/100/1000 RJ45 LAN Ports
• Interfaces: 1 × 10/100/1000 RJ45 LAN/WAN Port
• Interfaces: 1 × RJ11 Port
• Interfaces: 1 × USB 2.0 Port
• Button: RST
• IEEE Standards: IEEE802.11b/g/n, IEEE802.11ac, IEEE802.11ax, IEEE 802.3, 802.3u, IEEE802.1Q
• VDSL2 Standards: ITU G.993.2, Up to 17a /30a/35b profile
• VDSL2 Standards: ITU-T G.993.5 (G.vector)
• VDSL2 Standards: ITU-T G.998.4 (G.INP)
• ADSL Standards: Full-rate ANSI T1.413 Issue 2
• ADSL Standards: ITU-T G.992.1 (G.DMT)
• ADSL Standards: ITU-T G.992.2 (G.Lite)
• ADSL Standards: ITU-T G.994.1 (G.hs)
• ADSL2 Standards: ITU-T G.992.3 (G.dmt.bis)
• ADSL2+ Standards: ITU-T G.992.5
• Signal Rate: 300Mbps at 2.4GHz
• Signal Rate: 1201Mbps at 5GHz
• Antenna Type: 4 × 5 dBi Antenna
• Frequency: IEEE 802.11a/n/ac/ax 5GHz
• Frequency: IEEE 802.11b/g/n 2.4GHz
• Transmission Power: 2.4GHz <20dBm(EIRP)
• Transmission Power: 5GHz <23dBm(EIRP)
• Support Software: Advanced Features
• PVC Configuration
• DSL Settings
• Routing
• QoS (Based IP)
• Security: MAC Filtering
• Security: IP/Port Filtering
• Security: URL Blocking
• Security: DOS
• Operating Modes: VDSL/ADSL Modem Router
• Management: Web Based Conguration(HTTP)
• Management: Remote management
• Management: command Line Interface
• Management: SSL for TR-069
• Management: SNMP v1/2c
• Management: Web Based Firmware Upgrade
• Diagnostic Tools: DHCP
• DHCP: DHCP Server
• DHCP: Client List
• Address Reservation
• Port Forwarding
• Port Forwarding, UPnP, DMZ
• Dynamic DNS
• VPN Protocols: PPTP
• VPN Protocols: L2TP
• VPN Protocols: IPsec
• Protocols: Supports IPv4 and IPv6
• ATM/PPP Protocols: ATM Forum UNI3.1/4.0
• Protocols: PPP over ATM (RFC 2364)
• Protocols: PPP over Ethernet (RFC2516)
• Protocols: IPoA (RFC1577/2225)
• Protocols: MER/IPoE (RFC 1483 Routed)
• Protocols: Bridge (RFC1483 Bridge)
• PVC: Up to 8 PVCs
• Wireless Standards: IEEE 802.11a/n/ac/ax 5GHz; IEEE 802.11b/g/n 2.4GHz
• Wireless: Enable/Disable Wireless Radio
• Wireless Router feature list: Wireless Schedule
• Wireless parameters: 20M/40M/80M
• Certifications: CE、RoHS
• Dimensions (W x D x H): 220 x 141.6 x 59 mm
• Power: External Power Supply
• Power: 12V 1.5A
• Environment: Storage Temperature
• Environment: Operation Temperature 0℃~40℃ (32℉ ~104℉)
• Environment: Operating Humidity 10% ~ 90% (Non-condensing)
• Environment: Storage Humidity 5% ~ 90% (Non-condensing)
• Working temperature range also listed: 40℃ ~ 70℃
• Package Contents: External Splitter*1
• Package Contents: RJ11 DSL Cable*2
• Package Contents: RJ45 Ethernet Cable*1
• Package Contents: Quick Installation Guide*1
• Package Contents: AX1500 Dualband Wi‑Fi 6 Gigabit VDSL Modem Router*1
• Package Contents: Power Adapter*1
• Antenna count: 4
• Data Rate: AX1500
• Speed: Gigabit
