TP-Link Archer C6 AC1200 MU-MIMO Gigabit Router | Dual-Band Wi-Fi for High-Speed Connectivity

The TP-Link Archer C6 AC1200 MU-MIMO Gigabit Router delivers robust wireless performance and versatile connectivity options, ideal for both residential and small office environments. Utilizing the latest 802.11ac technology, this router provides dual-band speeds of up to 867 Mbps on the 5 GHz band and 400 Mbps on the 2.4 GHz band. This dual-band capability ensures optimal performance for activities ranging from casual web browsing to high-definition streaming and online gaming.

Four high-performance external antennas work in conjunction with beamforming technology to enhance coverage and signal strength throughout your home. This setup effectively eliminates dead zones and provides reliable connectivity across various spaces. Additionally, MU-MIMO technology allows multiple devices to connect simultaneously without degrading performance, making it suitable for households with multiple users. The Archer C6 also features advanced security with WPA3 encryption, ensuring that your network is protected from potential threats. The inclusion of Gigabit Ethernet ports further boosts wired connection speeds, making it a comprehensive solution for high-speed networking needs.

Key Features

• Dual-Band Wi-Fi: Operates on 2.4 GHz and 5 GHz bands, offering speeds of 400 Mbps and 867 Mbps respectively, perfect for diverse internet usage including streaming and gaming.
• High-Performance Antennas: Four external antennas and beamforming technology enhance signal strength and expand coverage throughout your home.
• MU-MIMO Technology: Supports simultaneous data streams to multiple devices, reducing congestion and improving overall network efficiency.
• Gigabit Connectivity: Includes one Gigabit WAN port and four Gigabit LAN ports, providing up to 10× faster speeds compared to standard Ethernet connections.
• Advanced Security: WPA3 encryption delivers improved protection against cyber threats and unauthorized access.
• Whole Home Mesh Capability: Compatible with OneMesh™ to create a seamless, multi-gigabit mesh network without needing to replace existing devices.
• Flexible Operation Modes: Can be used as a Router or Access Point to adapt to different network configurations.
• Easy Setup and Management: The Tether app for Android and iOS devices simplifies the setup process and network management.

Specifications

Standards

• Wi-Fi 5: IEEE 802.11ac/n/a 5 GHz, IEEE 802.11n/b/g 2.4 GHz

WiFi Speeds

• AC1200: 5 GHz: 867 Mbps (802.11ac), 2.4 GHz: 400 Mbps (802.11n)

WiFi Range

• 3 Bedroom Houses
• 4× Fixed High-Performance Antennas: Multiple antennas form a signal-boosting array to cover more directions and large areas
• Beamforming: Concentrates wireless signal strength towards clients to expand WiFi range

WiFi Capacity

• Medium
• Dual-Band: Allocate devices to different bands for optimal performance
• MU-MIMO: Simultaneously communicates with multiple MU-MIMO clients
• Airtime Fairness: Improves network efficiency by limiting excessive occupation

Working Modes

• Router Mode, Access Point Mode

SECURITY

• Network Security: SPI Firewall, Access Control, IP & MAC Binding, Application Layer Gateway
• Guest Network: 1× 5 GHz Guest Network, 1× 2.4 GHz Guest Network
• WiFi Encryption: WPA, WPA2, WPA3, WPA/WPA2-Enterprise (802.1x)

HARDWARE

• Processor: 1.2 GHz CPU
• Ethernet Ports: 1× Gigabit WAN Port, 4× Gigabit LAN Ports
• Buttons: WPS/Wi-Fi Button, Power On/Off Button, Reset Button
• Power: 12 V ⎓ 1 A

SOFTWARE

• Protocols: IPv4, IPv6
• OneMesh™: Supported, allowing the creation of a flexible network with TP-Link OneMesh™ products
• Parental Controls: URL Filtering, Time Controls
• WAN Types: Dynamic IP, Static IP, PPPoE, PPTP, L2TP
• Quality of Service: QoS by Device
• Cloud Service: OTA Firmware Upgrade, TP-Link ID, DDNS
• NAT Forwarding: Port Forwarding, Port Triggering, DMZ, UPnP
• IPTV: IGMP Proxy, IGMP Snooping, Bridge, Tag VLAN
• DHCP: Address Reservation, DHCP Client List, Server
• DDNS: TP-Link, NO-IP, DynDNS
• Management: Tether App, Webpage

OTHER

• System Requirements: Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser, Cable or DSL Modem (if needed), Subscription with an internet service provider (for internet access)
• Certifications: FCC, CE, RoHS
• Environment: Operating Temperature: 0℃~40℃ (32℉ ~104℉), Storage Temperature: -40℃~70℃ (-40℉ ~158℉), Operating Humidity: 10%~90% non-condensing, Storage Humidity: 5%~90% non-condensing

TEST DATA

• WiFi Transmission Power: CE EIRP: <20dBm(2.4GHz), <23dBm(5GHz), FCC: <30dBm(2.4GHz & 5GHz)
• WiFi Reception Sensitivity: 5GHz: 11a 6Mbps:-93dBm, 11a 54Mbps:-78dBm, 11ac HT20 mcs8: -69dBm, 11ac HT40 mcs9: -65dBm, 11ac HT80 mcs9: -62dBm, 2.4GHz: 11g 54Mbps:-78dBm, 11n HT20 mcs7: -74dBm, 11n HT40 mcs7: -71dBm

PHYSICAL

• Dimensions (W×D×H): 8.5 × 4.6 × 1.2 in (215 × 117 × 32 mm)
• Package Contents: Wi-Fi Router Archer C6, Power Adapter, RJ45 Ethernet Cable, Quick Installation Guide

Conclusion

The TP-Link Archer C6 AC1200 MU-MIMO Gigabit Router provides a high-performance networking solution for users seeking fast and reliable Wi-Fi. With its dual-band capabilities, advanced MU-MIMO technology, and enhanced security features, this router ensures efficient connectivity for all your devices. The combination of gigabit wired connections and extensive coverage makes it a practical choice for enhancing both wired and wireless network experiences throughout your home or office.
