Ubiquiti PoE Adapter (15W) - U-POE-AF

$30.00
$45.00
$30.00
Subtotal: $30.00
Order on Whatsapp
Vendor: Ubiquiti
SKU: U-POE-AF-R1-J
Availability: Many In Stock
Product Type: Wireless Routers
The U-POE-af Passive PoE Adapter is designed to power PoE devices from Ubiquiti Networks like the UniFi6 Lite. This 48 VDC adapter provides surge, clamping, maximum surge discharge, and peak pulse current protection to ensure that your connected PoE devices remain operational.

Specifications

Model U-POE-af
Dimensions 86 x 46 x 33 mm (3.39 x 1.81 x 1.30")
Weight 100 g (3.53 oz)
Output voltage 48V DC @ 0.32A
LAN activity indicator No
Gigabit LAN port Yes
Remote reset capability No
Reset Button No
Rated voltage 100—240V AC @ 50/60Hz
Input current 500mA Max.
Inrush current <100A Peak at 25°C
Efficiency 84.25+%
Output ripple 200mV p-p
Switching frequency 65 kHz
Line regulation ≤ 3%
Load regulation ≤ 5%
2-pair powering Pins 4, 5 (+) and 7, 8 (-)
4-pair powering No
AC connector IEC-320 C6
Data In / PoE RJ45 shielded socket
Surge protection Difference and common mode
Clamping protection 11V data, 60V power
Max. surge discharge 1500A (8/20 μs) power
Peak pulse current 36A (10/1000 μs) data
Shunt capacitance <5 pF data
Response time <1 ns
Ambient operating temperature 0 to 40° C (32 to 104° F)
Storage temperature -30 to 70°C (-22 to 158° F)
Ambient operating humidity 10 to 95% noncondensing
Certifications CE, FCC, IC, UL
