The Insta360 Electric Suction Cup Mount is engineered to deliver secure and stable mounting for action cameras during high-speed driving and cinematic car shoots. An electronic pump with a built-in sensor automatically removes air to maintain strong and steady suction, ensuring reliable attachment even on bumpy roads and winding mountain routes. Under laboratory conditions, a maximum holding force of 50kg can be achieved when mounted vertically on a flat surface, with a minimum holding force of 30kg maintained during continuous use.
Designed for endurance, up to 120 hours of battery life is supported on a single charge, with suction capable of lasting up to five days depending on conditions. The mount is rigorously tested to withstand impacts up to 800G and is built to handle extreme environments, including high altitudes and freezing temperatures down to 5°F (-15°C). A flexible double ball head with 360-degree rotation enables precise angle adjustment, while compatibility with NATO rails and the Insta360 Dual/Triple Suction Cup Car Mount (sold separately) allows expanded shooting configurations.
Key Features
Automatic Electronic Suction System
An integrated electronic pump with sensor technology continuously monitors and maintains suction strength. Air is automatically removed to ensure stable mounting without manual pumping.
One-Touch Instant Lock
Suction is activated instantly with a single press. Continuous monitoring ensures consistent holding force while attention remains focused on driving.
Proven 800G Impact Resistance
The mount is tested to handle impacts up to 800G, providing enhanced reliability for off-road drives and high-vibration conditions.
Up to 120 Hours Battery Life
A long-lasting rechargeable battery delivers up to 120 hours of operation, depending on usage conditions. Ideal for road trips and extended filming sessions.
Extreme Weather Performance
Reliable operation is supported in extreme environments, including high altitudes and temperatures as low as 5°F (-15°C).
Flexible 360° Double Ball Head
A dual ball head mechanism rotates 360 degrees, allowing precise angle control from the hood, roof, trunk, or side panels of a vehicle.
Expanded Compatibility
Compatible with NATO rails and Insta360 Dual/Triple Suction Cup Car Mount systems for additional mounting flexibility.
Safety Rope Support
A dedicated safety rope hole is included to attach a securing cord for additional protection during high-speed or steep driving conditions. (Safety rope sold separately.)
Specifications
Product Name: Insta360 Electric Suction Cup Mount
Mount Type: Electric Suction Car Mount
Maximum Holding Force (Lab Conditions): 50kg (vertical flat surface)
Minimum Holding Force (Continuous Use): 30kg
Impact Resistance: Up to 800G
Battery Life: Up to 120 hours (based on hourly suction refresh)
Temperature Resistance: Down to 5°F (-15°C)
Rotation: 360° Double Ball Head
Compatibility: NATO Rails; Insta360 Dual/Triple Suction Cup Car Mount (sold separately)
Safety Feature: Safety Rope Hole
Charging Port: USB-C (with silicone protective plug)
Important Usage Notes
-
The mount should not be dropped, hit, or thrown.
-
Use in rain is not recommended.
-
Prolonged exposure to grease or chemical solvents should be avoided.
-
The mounting surface must be smooth and clean before installation.
-
The mount should be pressed firmly against the surface before suction is activated.
-
The white filter cotton at the base must be kept clean to prevent dirt entry.
-
The USB-C silicone plug should remain sealed when not charging.
-
The suction cup should be cleaned after use to maintain performance.
-
Battery level should be checked while parked; if below 10%, full charging is recommended before reuse.
-
If unused for extended periods (e.g., 3 months), the battery should be recharged.
-
The mount should only be used according to official instructions and not combined with unauthorized accessories.
The Insta360 Electric Suction Cup Mount is designed to provide strong, sensor-controlled suction, extended battery performance, and impact-tested durability for cinematic car filming. Secure attachment, flexible angle adjustment, and compatibility with expanded mounting systems are combined to support professional-grade automotive shooting in demanding environments.
