MikroTik hAP ax² WiFi 6 Dual-Band Access Point with 5 Gigabit Ethernet Ports | C52iG-5HaxD2HaxD-TC

Upgrade your home network with the MikroTik hAP ax², a cutting-edge WiFi 6 dual-band access point designed to deliver exceptional wireless performance and coverage. Utilizing the latest 802.11ax technology with Wave2 support, this access point offers up to 40% higher speeds on the 5 GHz band and up to 90% higher speeds on the 2.4 GHz band compared to previous generations. The state-of-the-art dual-band, dual-chain radios with 4-4.5 dBi gain ensure strong and reliable signal strength throughout your home, eliminating dead zones and providing a stable connection for all your devices.

The hAP ax² is powered by a robust quad-core CPU running at 864 MHz and equipped with 1 GB of RAM, making it capable of handling complex networking tasks with ease. The advanced WPA3 encryption enhances your network's security, while the flexible mounting options (vertical, horizontal, or wall) ensure that the access point can be installed in various locations without compromising signal quality. Ideal for demanding households, the hAP ax² ensures fast and reliable connectivity for streaming, gaming, and large file transfers.

Key Features:

• WiFi 6 Technology: Utilizes the latest 802.11ax standard with Wave2 support for improved speed and efficiency.
• High-Speed Wireless: Provides up to 40% higher speed on the 5 GHz band and up to 90% higher speed on the 2.4 GHz band compared to older models.
• Powerful Performance: Equipped with a quad-core CPU running at 864 MHz and 1 GB of RAM for handling complex networking tasks and high traffic.
• Enhanced Security: Supports WPA3 encryption for advanced security and protection.
• Flexible Mounting Options: Can be mounted vertically, horizontally, or on the wall to fit various installation needs.

Specifications:

• Product Code: C52iG-5HaxD2HaxD-TC
• Architecture: ARM 64bit
• CPU: IPQ-6010
• CPU Core Count: 4
• CPU Nominal Frequency: 864 MHz
• Switch Chip Model: IPQ-6010
• RouterOS License: 4
• Operating System: RouterOS v7
• Size of RAM: 1 GB
• Storage Size: 128 MB
• Storage Type: NAND
• MTBF: Approximately 100,000 hours at 25°C
• Tested Ambient Temperature: -40°C to 50°C
• IPsec Hardware Acceleration: Yes

Wireless Capabilities:

• Wireless 2.4 GHz Max Data Rate: 574 Mbit/s
• Wireless 2.4 GHz Number of Chains: 2
• Wireless 2.4 GHz Standards: 802.11b/g/n/ax
• Antenna Gain dBi for 2.4 GHz: 4
• Wireless 2.4 GHz Chip Model: QCN-5022
• Wireless 2.4 GHz Generation: Wi-Fi 6
• Wireless 5 GHz Max Data Rate: 1200 Mbit/s
• Wireless 5 GHz Number of Chains: 2
• Wireless 5 GHz Standards: 802.11a/n/ac/ax
• Antenna Gain dBi for 5 GHz: 4.5
• Wireless 5 GHz Chip Model: QCN-5052
• Wireless 5 GHz Generation: Wi-Fi 6
• WiFi Speed: AX1800

Ethernet:

• 10/100/1000 Ethernet Ports: 5
• Number of 1G Ethernet Ports with PoE-Out: 1

Powering:

• Number of DC Inputs: 2 (DC Jack, PoE-IN)
• DC Jack Input Voltage: 12-28 V
• Max Power Consumption: 27 W
• Max Power Consumption Without Attachments: 12 W
• Cooling Type: Passive
• PoE In: Passive PoE
• PoE In Input Voltage: 18-28 V

PoE-Out:

• PoE-Out Ports: Ether 1
• PoE Out: Passive PoE
• Max Out Per Port Output (Input 18-30 V): 600 mA
• Max Total Out (A): 0.6 A
• Total Output Current: 0.6
• Total Output Power: 16.8 W

Certification & Approvals:

• Certification: CE, FCC, IC, EAC, ROHS
• IP Rating: IP20

Other:

• CPU Temperature Monitor: Yes
• Mode Button: Yes

Wireless Specifications:

• 2.4 GHz Transmit (dBm):

  • 1 MBit/s: 27
  • 11 MBit/s: 27
  • 6 MBit/s: 27
  • 54 MBit/s: 25
  • MCS0: 27
  • MCS7: 24
  • MCS9: 22
  • MCS11: 20

• 2.4 GHz Receive Sensitivity:

  • 1 MBit/s: -100
  • 11 MBit/s: -94
  • 6 MBit/s: -96
  • 54 MBit/s: -80
  • MCS0: -96
  • MCS7: -75
  • MCS9: -70
  • MCS11: -67

• 5 GHz Transmit (dBm):

  • 6 MBit/s: 26
  • 54 MBit/s: 23
  • MCS0: 26
  • MCS7: 22
  • MCS9: 20
  • MCS11: 18

• 5 GHz Receive Sensitivity:

  • 6 MBit/s: -96
  • 54 MBit/s: -80
  • MCS0: -96
  • MCS7: -75
  • MCS9: -70
  • MCS11: -67

Conclusion:

The MikroTik hAP ax² offers advanced WiFi 6 capabilities combined with high-speed performance and exceptional coverage. Designed for both home and small office environments, this access point ensures a reliable and secure connection. With its versatile mounting options, high-speed wireless performance, and robust security features, the hAP ax² stands out as a powerful and dependable choice for enhancing your network infrastructure.
