Tenda HD Network Video Recorder Poe 8 Channels TN3108-8P

The Tenda TN3108-8P HD Network Video Recorder is an 8-channel PoE UHD network video recorder designed for video recording, decoding, and playback with support for video and audio streams. It supports H.265+ / H.265 / H.264+ / H.264 video decoding and G.711A / G.711U / G726 audio decoding formats. Recording resolution options include 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 720P, and D1. With a decoding capability listed as 4-ch@1080P(30 fps) and sync playback up to 8-ch, this recorder is suited to multi-channel setups where you want managed playback and basic recording control modes. For connectivity, the unit provides PoE with 8 RJ45, 10Mbps/100Mbps auto-negotiation Ethernet ports, using IEEE 802.3at/802.3af. Network management includes Client support and mobile/PC applications via TDSEE (mobile phone) and TDSEE STUDIO (PC). The recorder includes backup mode via USB device, supports network protocols such as HTTP, HTTPS, WebSockets, TCP/IP, IPv4, RTSP, UDP, NTP, DHCP, DNS, and DDNS, and offers web browser access with plug-in free live view in Chrome, Edge, and Opera. For output, it includes HDMI output (1-ch, 4K/30Hz and additional listed resolutions) and VGA output (1-ch), with HDMI/VGA simultaneous output.
Key Features
• 8-Channel PoE UHD Network Video Recorder
• 60 Mbps
• Video&Audio Decoding
• Video Decoding Format: H.265+, H.265, H.264+, H.264
• Audio Decoding Format: G.711A, G.711U, G726
• Recording Resolution: 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 720P, D1
• Decoding Capability: 4-ch@1080P(30 fps)
• Stream Type: Video, Video & Audio
• Recording Mode: Normal, Alarm
• Playback Mode: Instant, Channel, File, Tag
• Sync Playback: Up to 8-ch
• Backup Mode: USB device
• Network Managemants: Client
• TDSEE (mobile phone)
• TDSEE STUDIO (PC)
• PoE Port: 8 RJ45, 10Mbps/100Mbps auto-negotiation Ethernet ports
• PoE Standard: IEEE 802.3at/802.3af
• HDD Interface: 1 SATA 3.0 interface
• Installation Method: Desktop mounting, wall mounting
• Desktop mounting, wall mounting
• USB Port: 2 x USB 2.0
• IP Video Input: 8-ch, Up to 8MP
• HDD Interface: 1 SATA 3.0 interface (Up to 10 TB for each HDD)
• Ethernet Port: 1 RJ45, 10Mbps/100Mbps auto-negotiation Ethernet port
• Application Remote Monitoring
• Channel cloud Storage
• HDMI Output: 1-ch
• VGA Output: 1-ch
• HDMI/VGA simultaneous output
• Audio Output: 1-ch, RCA (2.0 Vp-p, 10kΩ)
• Power Protection
• Plug and Play
• - 4K UHD Input & Output
• - Transmission Distance: 250 meters
• - External Interface: 2 x USB 2.0
Specifications
• Reference: NETWORK L102
• Power: POE
• PoE Power: ≤70 W
• Power: 53VDC, 2.25A
• Certification: CCC, CE, FCC, RoHS
• Video: 8-ch
• IP Video Resolution: Up to 8MP
• Network: Ethernet Port: 1 RJ45, 10Mbps/100Mbps auto-negotiation Ethernet port
• Network Protocol: HTTP, HTTPS, WebSockets, TCP/IP, IPv4, RTSP, UDP, NTP, DHCP, DNS, DDNS
• Web Browser
• External Interface: USB Port: 2 x USB 2.0
• HDMI Output: 1-ch, 4K(3840×2160)/30Hz, 2560 × 1440/30Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
• VGA Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
• HDMI/VGA simultaneous output
• Audio Output: 1-ch, RCA (2.0 Vp-p, 10kΩ)
• HDD Interface: 1 SATA 3.0 interface
• Capacity: Up to 10 TB capacity for each HDD
• Dimension: 255 mm x 216 mm x 44 mm (10 × 8.5 × 1.9)
• Weight (Without HDD): 768g (1.69lb)
• Operating Temperature: 0°C - 40°C (32°F - 104°F)
• Storage Temperature: -30°C - 70°C (-22°F - 158°F)
• Operating Humidity: 10% - 90% RH (non-condensing)
• Storage Humidity: 5% - 95% RH (non-condensing)
• IP Video Input: 8-ch
• Transmission Distance: 250 meters
• Installation Method: Desktop mounting, wall mounting
• Power Protection
• Plug and Play
• Plug-in free live view: Chrome, Edge, Opera
