Tenda Router SG04 APC XPON ONT 4 GE Ethernet ports Gigabit

Name: Tenda SG04 APC xPON ONU 4 GE Gigabit
Brand: Tenda
SKU: SG04-APC-R55-J
Price: 45.0 USD
Availability: InStock

Excluding VAT

$45.00

Quantity

Subtotal: $45.00

Add to wishlist

Vendor: Tenda
SKU: SG04-APC-R55-J
Availability:
Product Type: Network Switches

Every product sold by 961 Souq is sourced from trusted suppliers and verified before dispatch. We only list genuine items with clear product details, warranty information, and after-sales support.

Product images are for reference only. The actual item may differ in appearance & colour. Please refer to the product code, SKU, and description from manufacturer website for accurate specifications.

The Tenda SG04 APC XPON ONT is a gigabit xPON ONU designed for business internet connectivity using 4×1000Mbps RJ45 LAN ports. It supports both EPON and GPON operation with stated bandwidth limits, including EPON upstream and downstream rates of up to 1.244Gbps each, and GPON upstream up to 1.244Gbps and downstream up to 2.488Gbps. The unit uses an optical interface specified as 1×SC/APC or SC/UPC (optional) port, and provides visible status through LEDs for PON, LOS, and LAN. With support for bridge mode and IPv4, it fits network setups where bridging is required. For optical link performance, the SG04 is specified with transmit wavelength at 1310nm and receive wavelength at 1490nm, with a transmission distance of up to 20km. Optical mode is listed as Class B+, and optical power is given for TX power and RX power. The product includes a 1×RST button and a DC power port, with local web management and optical power monitoring noted as software features. Environmental operating and storage ranges are provided, including operating temperature of 20℃ ~ 55℃ and storage temperature of -40℃ ~ 70℃, along with humidity ranges for both operating and storage conditions.
Key Features
• 4GE xPON ONU
• Standards: ITU G.984.1, ITU G.984.2, ITU G.984.3, ITU G.984.4
• Interface: 1*SC/APC or SC/UPC (optional) Port
• 4*1000Mbps RJ45 LAN Ports
• LEDs: PON, LOS, LAN
• Button: 1*RST Button
• Optical Mode: Class B+
• Optical Wavelength: Transmit at 1310nm, Receive at 1490nm
• Transmission Distance: 20km Max
• Bandwidth: EPON Upstream 1.244Gbps Max, Downstream 1.244Gbps Max
• Bandwidth: GPON Upstream 1.244Gbps Max, Downstream 2.488Gbps Max
• Software Features: WAN Connection, Bridge Mode
• Business Type: Internet
• IP Version: IPv4
• Supports bridge mode access
• Local Web management and optical power monitors
• Standards/Technology: IEEE802.3ah
Specifications
• Interface: 1 *SC/APC or SC/UPc (Optional)
• Interface: 4 *1000Mbps RJ45 LAN
• Interface: 1 *DC Power Port
• Optical wavelength: Transmit at 1310nm
• Optical wavelength: Receive at 1490nm
• Transmission Distance: 20km Max
• Optical power range: 0.5~5dBm
• End face: Angled 8 degree
• Return loss: -60 dB or better
• Insertion loss: slightly higher
• Color: Green
• Application: Analog/Video/RF/FTTX
• Interconnection: not compatible with UPC
• External Power Supply: DC 12V /1A
• DC power port: 1*DC Power
• Dimensions (L×W×H): 100×100×26mm
• TX Power: 28~-8dBm
• RX Power: (not separately specified beyond provided TX/RX value range)
• Lightning Surge: GE: Differential mode 1KV; Common mode 6KV
• Lightning Surge: AC Power: Differential mode 4KV; Common mode 4KV
• Operating Temperature: 20℃ ~ 55℃
• Storage Temperature: -40℃ ~ 70℃
• Operating Humidity: 10% ~ 95% (Non-condensing)
• Storage Humidity: 5% ~ 90% (Non-condensing)
• Power Consumption: ≤3w
• Reference: NETWORK L41
• Speed: Gigabit
