TP-Link LS105GP 5-Port Gigabit Desktop Switch with 4-Port PoE+ | High-Speed Connectivity & Power over Ethernet

Upgrade your network with the TP-Link LS105GP 5-Port Gigabit Desktop Switch, featuring 4 PoE+ ports for versatile connectivity and efficient power distribution. This high-performance switch offers a range of features designed to enhance your network's efficiency, reliability, and flexibility.

Full Gigabit Performance
Equipped with five gigabit ports, the LS105GP provides up to 10 Gbps switching capacity, ensuring fast and reliable network performance. The switch supports auto-negotiation and auto MDI/MDIX for seamless connectivity and ease of use.

Efficient Power over Ethernet (PoE+)
The LS105GP includes four PoE+ ports that comply with IEEE 802.3af/at standards. Each port supports up to 30 W of power output, enabling you to connect and power devices such as IP cameras, access points, and IP phones with a single cable. The 65 W PoE budget ensures adequate power for multiple devices.

Extended PoE Transmission
Utilize Extend Mode to achieve PoE transmission distances of up to 250 meters. This feature is particularly beneficial for deploying surveillance cameras or other PoE-powered devices in large or expansive areas.

Automatic PoE Recovery
The switch is equipped with PoE Auto Recovery, a feature that automatically reboots unresponsive or dropped PoE-powered devices, minimizing downtime and maintaining network stability.

Plug and Play Convenience
Installation is straightforward with plug and play functionality. No configuration is required, making it easy to integrate the switch into your existing network setup.

Silent and Reliable Operation
Designed with a fanless architecture, the LS105GP operates silently, making it ideal for noise-sensitive environments. The durable metal casing ensures reliability and longevity, while the versatile desktop or wall-mounting installation options provide flexibility in placement.

Key Features

• Gigabit Ports: 5 × 10/100/1000 Mbps RJ45 ports for high-speed network connectivity.
• PoE+ Support: 4 × 802.3af/at-compliant PoE+ ports, each providing up to 30 W of power.
• Extended PoE Transmission: Up to 250 meters with Extend Mode for wide-area deployments.
• PoE Auto Recovery: Automatically reboots unresponsive PoE devices for continuous operation.
• Plug and Play: Easy setup with no configuration required.
• Silent Operation: Fanless design for noise-free performance.
• Durable Design: Metal casing and flexible installation options (desktop or wall-mount).

Specifications

Hardware Features

• Interface: 5 × 10/100/1000 Mbps RJ45 Ports (Ports 1–4 support 802.3af/at PoE+)
• Network Media: UTP category 3, 4, 5 cable (max 100m); STP (max 100m)
• Fan Quantity: Fanless
• Installation: Desktop or Wall Mounting
• Power Supply: External Power Adapter (53.5 VDC / 1.31 A)
• PoE Ports: Ports 1–4, up to 30 W per port
• Dimensions (W x D x H): 3.9 × 3.9 × 1.0 in (99.8 × 98 × 25 mm)
• Max Power Consumption: 4 W (no PD connected); 74.46 W (with 65 W PD connected)
• Max Heat Dissipation: 13.6 BTU/h (no PD connected); 253.16 BTU/h (with 65 W PD connected)

Performance

• Switching Capacity: 10 Gbps
• Packet Forwarding Rate: 7.44 Mpps
• MAC Address Table: 2K
• Jumbo Frame: 16 KB

Software Features

• Advanced Features: Extend Mode Button, PoE Auto Recovery Button, IEEE 802.3af/at compliance, MAC Address Auto-Learning and Auto-Aging, IEEE 802.3x Flow Control, 802.1p/DSCP QoS, IGMP Snooping, Green Technology
• Transfer Method: Store-and-Forward

Others

• Certification: FCC, CE, RoHS
• Package Contents: LS105GP Switch, Power Adapter, Installation Guide
• Environment: Operating Temperature: 0–40 ℃ (32–104 ℉); Storage Temperature: -40–70 ℃ (-40–158 ℉); Operating Humidity: 10–90% RH non-condensing; Storage Humidity: 5–90% RH non-condensing

Conclusion

The TP-Link LS105GP 5-Port Gigabit Desktop Switch offers a powerful and versatile solution for expanding your network. With its high-speed gigabit ports, PoE+ support, and extended transmission capabilities, it is ideal for powering and connecting a variety of devices in both home and business environments. Enjoy reliable, efficient, and silent network performance with the LS105GP, and simplify your network management with its plug-and-play functionality and advanced features.
