Linksys 24-Port Managed Gigabit Ethernet Switch with 4 10G SFP+ Uplinks LGS328C for Advanced Network Security and High-Speed Connectivity

The Linksys 24-Port Managed Gigabit Ethernet Switch LGS328C is engineered to provide your business with exceptional network speed and security. Featuring 24 Gigabit Ethernet ports and 4 10G SFP+ uplinks, this switch delivers robust and reliable connectivity, making it ideal for handling high-demand applications and large-scale data transfers. Designed with advanced security features and quality of service (QoS) capabilities, it ensures that your network operates smoothly while protecting against potential threats.

This managed switch offers extensive configuration options, allowing for precise control over your network traffic. With TAA compliance and a host of advanced features, including VLAN support, rate limiting, and remote monitoring (RMON), the LGS328C is perfect for businesses seeking to optimize their network infrastructure. The switch's power efficiency, combined with its robust security measures, provides a reliable and energy-conscious solution for any enterprise.

Key Features:

• 24 Gigabit Ethernet Ports: Provides fast and stable connections for a wide range of devices, ensuring consistent network performance.
• 4 10G SFP+ Uplinks: Delivers high-speed uplinks for seamless data transfer and expanded network capacity.
• Advanced Security Features: Includes 802.1x Radius authentication, DHCP snooping, DOS attack prevention, IP-MAC binding, and port isolation to safeguard your network.
• Quality of Service (QoS): Supports 8 hardware queues, ensuring that critical network traffic is prioritized for optimal performance.
• VLAN Support: Offers port-based and 802.1q VLANs, management VLAN, and guest VLAN support, providing flexible network segmentation.
• Power Efficiency: Complies with Energy Efficient Ethernet (EEE) standards, reducing energy consumption without compromising performance.
• Managed Switch: Provides extensive control over network settings with features like static routing, link aggregation, and access control lists (ACLs).

Specifications (Rewritten):

• Switch Type: Managed
• Switch Ports: 24 Gigabit Ethernet
• Power Consumption: Operates at 23.95W
• Jumbo Frame Support: Handles frames up to 12Kbytes for efficient data processing.
• LED Indicators: Includes indicators for power and fault status.
• VLAN Capabilities: Supports port-based and 802.1q VLANs, management VLAN, and guest VLAN.
• Memory: Equipped with 512MB memory for smooth operation.
• Forwarding Rate: Capable of 95.23 Mpps, ensuring swift data handling.
• Dimensions: Measures 330 x 230 x 44 mm (12.99 x 9.06 x 1.73 in.).
• Weight: Weighs 1989 g (4.38 lb).
• VLAN Support: Accommodates up to 256 active VLANs within a range of 4,096.
• Operating Conditions: Functions within 10 to 90% relative humidity and temperatures of 0 to 45°C (32 to 113°F).
• Security Features: Includes 802.1x Radius authentication, DHCP snooping, DOS attack prevention, IP-MAC binding, port isolation, and port security (256 entries per port).
• Rate Limiting: Offers rate limiting from 12kbps to 1000Mbps, adjustable in 16kbps increments.
• Power Input: Requires 0.7A, 100–240V, 50–60 Hz.
• Spanning Tree Protocol: Supports IEEE 802.1d, 802.1w Rapid Spanning Tree, and 802.1s Multiple Spanning Trees (up to 16 instances).
• Quality of Service: Provides 8 hardware queues with port-based, 802.1p, and IPv4/v6 IP DSCP-based prioritization.
• Storage Conditions: Suitable for storage at temperatures from 0 to 45°C (32 to 113°F) and humidity levels of 5 to 95% (non-condensing).
• Remote Monitoring: Includes RMON 1, 2, 3, and 9 for enhanced traffic management and analysis.
• MAC Address Table Size: Supports up to 16K MAC addresses.
• Switching Capacity: Capable of handling up to 128 Gbps.
• HOL Blocking Prevention: Equipped with Head of Line (HOL) blocking prevention.
• Auto Voice VLAN: Automatically assigns voice traffic to a specific VLAN, ensuring optimal handling of voice data.
• Management Interface: Accessible via HTTP, HTTPS, and includes console port, DHCP client, system log, and dual images.
• Link Aggregation: Supports IEEE 802.3ad LACP, allowing up to 8 groups with 8 ports per group.
• Access Control: Features ACLs based on ingress, MC, IPv4, IPv6, with permit/deny actions.
• Storm Control: Protects against broadcast, unknown multicast, and unknown unicast traffic with rate limiting from 16kbps to 1000Mbps.
• Routing Capabilities: Supports static routing with up to 63 IPv4 and 21 IPv6 entries.
• SNMP Support: Compatible with SNMP versions 1, 2c, and 3.
• IGMP Snooping: Enhances multicast management, supporting IGMP v1/v2/v3 and up to 256 multicast groups.
• Power Saving: Complies with Energy Efficient Ethernet (EEE) standards.
• Port Mirroring: Allows traffic on up to 3 ports to be mirrored for network analysis.
• Firmware Upgrade: Can be upgraded via web browser (HTTP/HTTPS).

Conclusion: The Linksys 24-Port Managed Gigabit Ethernet Switch LGS328C is a comprehensive solution for businesses seeking advanced network security, high-speed connectivity, and efficient management. Its extensive features and robust performance ensure that your network is equipped to handle the demands of modern business environments.
