TP-Link TL-SG1048 - 48-Port Gigabit Rackmount Switch

The TP-Link TL-SG1048 48-Port Gigabit Rackmount Switch is engineered to meet the connectivity demands of high-performance workgroups and departmental networks. With 48 auto-negotiation RJ45 ports, this switch supports seamless data transfers at gigabit speeds, making it an ideal solution for expanding network capacity without the complexity of management. Designed for cost-conscious network administrators, the TL-SG1048 combines ease of use with exceptional performance, offering reliable connectivity at an excellent value.

Equipped with TP-Link's Green Technology, the TL-SG1048 reduces power consumption by automatically adjusting based on link status, helping to minimize your network's carbon footprint. The switch also complies with RoHS standards, prohibiting the use of hazardous materials, and features recyclable packaging, making it an environmentally friendly choice for your business.

Key Features

• 48 Gigabit Ports: Provides 48× 10/100/1000 Mbps RJ45 ports with Auto MDI/MDIX, enabling straightforward plug-and-play connectivity without the need for crossover cables.
• Energy-Efficient Technology: Utilizes innovative TP-Link Green Technology to reduce power consumption based on link status and cable length, offering an eco-friendly networking solution.
• High Performance: Delivers a non-blocking switching capacity of 96 Gbps and a packet forwarding rate of 71.4 Mpps, ensuring maximum data throughput for high-demand applications.
• Advanced Flow Control: Supports IEEE 802.3x flow control for full-duplex mode and backpressure for half-duplex mode, helping to alleviate traffic congestion and maintain reliable data transmission.
• Flexible Installation: The 19-inch, 1U rack-mountable design, along with the included mounting bracket, provides versatility for various networking environments, from small offices to large data centers.
• User-Friendly Operation: Auto-negotiation on each port automatically senses the link speed of connected devices and adjusts for optimal performance, while dynamic LED lights offer real-time status updates and basic fault diagnostics.

Specifications

Hardware Features

• Standards and Protocols:
  • IEEE 802.3i
  • IEEE 802.3u
  • IEEE 802.3ab
  • IEEE 802.3x
• Interface:
  • 48× 10/100/1000 Mbps RJ45 Ports
  • Auto Negotiation/Auto MDI/MDIX
• Network Media:
  • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
  • 100BASE-TX/1000BASE-T: UTP category 5, 5e, or above cable (maximum 100m)
• Physical Security Lock: No
• Power Supply: 100-240VAC, 50/60Hz
• Dimensions (W x D x H): 17.3 × 8.7 × 1.7 in. (440 × 220 × 44 mm)
• Mounting: 19" 1U Rack Mountable (mounting bracket included)
• Max Power Consumption: 32.3W
• Max Heat Dissipation: 110.2 BTU/h

Performance

• Switching Capacity: 96 Gbps
• Packet Forwarding Rate: 71.4 Mpps
• MAC Address Table: 16K
• Buffer Memory: 12Mb
• Jumbo Frame: 12KB
• Transfer Method: Store-and-Forward

Others

• Certification: FCC, CE, RoHS
• Package Contents:
  • 48-Port Gigabit Rackmount Switch
  • Power Cord
  • Installation Guide
  • Rackmount Kits
  • Rubber Feet
• Environment:
  • Operating Temperature: 0℃~40℃ (32℉~104℉)
  • Storage Temperature: -40℃~70℃ (-40℉~158℉)
  • Operating Humidity: 10%~90% non-condensing
  • Storage Humidity: 5%~90% non-condensing

Conclusion

The TP-Link TL-SG1048 48-Port Gigabit Rackmount Switch offers a robust, energy-efficient solution for expanding network capacity in demanding environments. Its high-performance architecture, combined with easy installation and eco-friendly design, makes it an excellent choice for enhancing network infrastructure with minimal effort and maximum value.
