TP-Link TL-SG1024 - 24-Port Gigabit Rackmount Switch

The TP-Link TL-SG1024 24-Port Gigabit Rackmount Switch offers a robust and efficient solution for upgrading your network to gigabit speeds. Designed with 24 auto-negotiation RJ45 ports, this switch provides seamless connectivity with plug-and-play functionality, making it ideal for both small businesses and enterprise networks. Its rack-mountable steel case fits standard 19-inch racks, allowing easy integration into your existing network infrastructure without complicated configurations.

Utilizing TP-Link's advanced Green Technology, the TL-SG1024 automatically adjusts power consumption based on the link status, significantly reducing energy usage and operating costs. This environmentally friendly approach not only minimizes your network's carbon footprint but also ensures compliance with RoHS standards by prohibiting the use of hazardous materials. The fanless design of the switch ensures quiet operation, making it suitable for any office or business environment.

Key Features

• 24 Gigabit Ports: Equipped with 24× 10/100/1000 Mbps RJ45 ports that support Auto MDI/MDIX, simplifying the connection process with plug-and-play installation and eliminating the need for crossover cables.
• Energy-Efficient Operation: TP-Link Green Technology automatically adjusts energy consumption based on link status and cable length, providing significant power savings while supporting environmentally sustainable networking.
• High Performance: Featuring a 48 Gbps switching capacity, 35.7 Mpps packet forwarding rate, and 10KB Jumbo Frame support, this switch ensures fast and reliable data transfer, making it perfect for large file transfers and high-performance networking tasks.
• Rackmount Design: The switch’s standard 19-inch rack-mountable steel case allows for easy installation in server racks, offering a sturdy and professional networking solution for office environments.
• Ease of Use: With its auto-negotiation feature, the switch automatically senses the link speed of connected devices, adjusting for compatibility and optimizing performance without manual configuration.

Specifications

Hardware Features

• Standards and Protocols:
  • IEEE 802.3i
  • IEEE 802.3u
  • IEEE 802.3ab
  • IEEE 802.3x
• Interface:
  • 24× 10/100/1000 Mbps RJ45 Ports
  • Auto Negotiation/Auto MDI/MDIX
• Network Media:
  • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
  • 100BASE-TX/1000BASE-T: UTP category 5, 5e, or above cable (maximum 100m)
• Fan Quantity: Fanless
• Physical Security Lock: No
• Power Supply: 100-240VAC, 50/60Hz
• Dimensions (W x D x H): 17.3 × 7.1 × 1.7 in (440 × 180 × 44 mm)
• Mounting: 19" Rack Mountable
• Max Power Consumption: 13.6W
• Max Heat Dissipation: 46.4 BTU/h

Performance

• Switching Capacity: 48 Gbps
• Packet Forwarding Rate: 35.7 Mpps
• MAC Address Table: 8K
• Jumbo Frame: 10KB
• QoS: 802.1p/DSCP QoS (for V11 and later versions)
• Green Technology: Yes
• Transfer Method: Store-and-Forward

Others

• Certification: FCC, CE, RoHS
• Package Contents:
  • 24-Port Gigabit Rackmount Switch
  • Power Cord
  • Installation Guide
  • Rackmount Kits
  • Rubber Feet
• Environment:
  • Operating Temperature: 0℃~40℃ (32℉~104℉)
  • Storage Temperature: -40℃~70℃ (-40℉~158℉)
  • Operating Humidity: 10%~90% non-condensing
  • Storage Humidity: 5%~90% non-condensing

Conclusion

The TP-Link TL-SG1024 24-Port Gigabit Rackmount Switch delivers high performance, energy efficiency, and ease of use, making it an excellent choice for businesses seeking to expand their network capacity. With its plug-and-play installation, eco-friendly operation, and robust design, this switch provides a reliable and cost-effective solution for enhancing network connectivity while minimizing environmental impact.
