MikroTik OmniTIK 5 PoE ac - 5GHz Dual Chain AP with 802.11ac, 7.5dBi Antennas, and 5 Gigabit Ethernet Ports with PoE-Out | RBOmniTikPG-5HacD

The MikroTik OmniTIK 5 PoE ac represents a notable enhancement to our line of 5GHz access points, designed to deliver robust and high-speed wireless performance. Featuring support for the latest 802.11ac standard, this access point is equipped with five Gigabit Ethernet ports and integrates dual-polarized 7.5dBi antennas to ensure optimal coverage and signal strength. The OmniTIK 5 PoE ac is powered by a 720MHz CPU and 128MB RAM, enabling efficient processing and reliable operation.

The access point is housed in a weatherproof enclosure, making it ideal for outdoor use in various environmental conditions. It supports both passive and standard 802.3at/af PoE input and output, with the added benefit of powering other PoE-capable devices through ports 2-5. This feature reduces the need for multiple power adapters and simplifies installation. The package includes a power supply, PoE injector, and mounting kit, providing everything needed for setup and deployment.

Key Features:

• Enhanced Wireless Performance: Supports 802.11ac Wi-Fi 5 with up to 867 Mbit/s data rate, ensuring high-speed and reliable wireless connectivity.
• Robust Outdoor Design: The weatherproof enclosure and dual-polarized 7.5dBi omni antennas make it suitable for challenging outdoor environments, offering excellent signal coverage.
• Flexible Power Options: Provides both passive and standard 802.3at/af PoE input/output, with the capability to power additional PoE devices via ports 2-5.
• Efficient Processing: Equipped with a 720MHz CPU and 128MB RAM, delivering robust performance for demanding networking tasks.
• Comprehensive Package: Includes a power supply, PoE injector, and mounting kit for easy installation and deployment.

Specifications:

• Product Code: RBOmniTikPG-5HacD
• Architecture: MIPSBE
• CPU: QCA9557
• CPU Core Count: 1
• CPU Nominal Frequency: 720 MHz
• Switch Chip Model: QCA8337
• Dimensions: 416 x 129 x 58 mm
• RouterOS License: 4
• Operating System: RouterOS
• Size of RAM: 128 MB
• Storage Size: 16 MB
• Storage Type: FLASH
• MTBF: Approximately 200,000 hours at 25°C
• Tested Ambient Temperature: -40°C to 70°C

Powering:

• Number of DC Inputs: 1 (PoE-IN)
• Max Power Consumption: 66 W
• Max Power Consumption Without Attachments: 18 W
• Cooling Type: Passive
• PoE In: Passive PoE
• PoE In Input Voltage: 12-57 V

PoE-Out:

• PoE-Out Ports: Ether2-Ether5
• PoE Out: 802.3af/at
• Max Out Per Port Output (Input 18-30 V): 1 A
• Max Out Per Port Output (Input 30-57 V): 450 mA
• Max Total Out (A): 2 A

Wireless Specifications:

• Wireless 5 GHz Max Data Rate: 867 Mbit/s
• Wireless 5 GHz Number of Chains: 2
• Wireless 5 GHz Standards: 802.11a/n/ac
• Antenna Gain dBi for 5 GHz: 7.5
• Wireless 5 GHz Chip Model: QCA9892
• Wireless 5 GHz Generation: Wi-Fi 5

Ethernet:

• 10/100/1000 Ethernet Ports: 5

Peripherals:

• Number of USB Ports: 1
• USB Power Reset: Yes
• USB Slot Type: USB Type A
• Max USB Current (A): 1

Other:

• PCB Temperature Monitor: Yes
• Voltage Monitor: Yes
• Beeper: Yes

Certification & Approvals:

• Certification: CE, FCC, IC, EAC, ROHS
• IP: IP54

Conclusion:

The MikroTik OmniTIK 5 PoE ac stands out as a high-performance access point suitable for demanding outdoor environments. With its advanced 802.11ac support, dual-polarized antennas, and multiple Gigabit Ethernet ports, it ensures superior wireless coverage and connectivity. Its weatherproof design and versatile power options further enhance its suitability for various installations. The inclusion of a comprehensive installation package adds to its convenience, making the OmniTIK 5 PoE ac a reliable choice for expanding your network capabilities.
