MikroTik mANTBox 52 15s - Dual-Band Outdoor Base Station with PoE, Gigabit Ethernet, and SFP | RBD22UGS-5HPacD2HnD-15S

The MikroTik mANTBox 52 15s is a versatile dual-band base station designed to enhance your outdoor wireless network with its robust features and advanced connectivity options. Ideal for managing diverse access points and CPE devices, this device offers exceptional performance across both 2.4 GHz and 5 GHz bands, making it suitable for various networking setups.

Equipped with a quad-core IPQ-4019 CPU and 256 MB of RAM, the mANTBox 52 15s handles heavy loads with ease and supports IPsec hardware offloading. The dual polarization antenna provides up to 20 km of coverage, ensuring reliable and extensive wireless connections. With support for Gigabit Ethernet and SFP fiber connections, this device is designed for high-speed and flexible networking solutions.

Key Features:

• Dual-Band Performance: Operates on both 2.4 GHz and 5 GHz frequencies, supporting simultaneous use for optimal network efficiency.
• High Processing Power: Features a quad-core IPQ-4019 CPU and 256 MB RAM for superior performance and handling of demanding tasks.
• Extended Coverage: Dual polarization antenna offers up to 20 km range, ideal for long-distance point-to-multipoint connections.
• Advanced Connectivity: Includes Gigabit Ethernet and SFP ports for versatile and high-speed network integration.
• IPsec Hardware Acceleration: Supports IPsec hardware offloading for enhanced security and performance.

Specifications:

• Product Code: RBD22UGS-5HPacD2HnD-15S
• Architecture: ARM 32-bit
• CPU: IPQ-4019
• CPU Core Count: 4
• CPU Nominal Frequency: Auto MHz
• Switch Chip Model: IPQ-4019
• Dimensions: 140 x 348 x 82 mm
• RouterOS License: 4
• Operating System: RouterOS
• Size of RAM: 256 MB
• Storage Size: 16 MB
• Storage Type: FLASH
• MTBF: Approximately 200,000 hours at 25°C
• Tested Ambient Temperature: -40°C to +70°C
• IPsec Hardware Acceleration: Yes

Powering:

• Number of DC Inputs: 2 (DC jack, PoE-IN)
• DC Jack Input Voltage: 12-57 V
• Cooling Type: Passive
• PoE In: 802.3af/at
• PoE In Input Voltage: 12-57 V

Wireless Specifications:

• Wireless 2.4 GHz Max Data Rate: 300 Mbit/s
• Wireless 2.4 GHz Number of Chains: 2
• Wireless 2.4 GHz Standards: 802.11b/g/n
• Antenna Gain dBi for 2.4 GHz: 12
• Wireless 2.4 GHz Chip Model: IPQ-4019
• Wireless 2.4 GHz Generation: Wi-Fi 4
• Wireless 5 GHz Max Data Rate: 867 Mbit/s
• Wireless 5 GHz Number of Chains: 2
• Wireless 5 GHz Standards: 802.11a/n/ac
• Antenna Gain dBi for 5 GHz: 15
• Wireless 5 GHz Chip Model: IPQ-4019
• Wireless 5 GHz Generation: Wi-Fi 5

Ethernet:

• 10/100/1000 Ethernet Ports: 1

Fiber:

• SFP Ports: 1

Peripherals:

• Number of USB Ports: 1
• USB Power Reset: Yes
• USB Slot Type: USB type A
• Max USB Current (A): 1

Other:

• PCB Temperature Monitor: Yes
• Voltage Monitor: Yes

Certification & Approvals:

• Certification: CE, FCC, IC, EAC, ROHS
• IP Rating: IP55

Conclusion:

The MikroTik mANTBox 52 15s is an advanced and powerful base station designed for extensive outdoor wireless network deployments. With its dual-band capabilities, high-performance CPU, and comprehensive connectivity options, it provides a robust solution for achieving reliable and high-speed wireless connections over long distances. Its durable construction and advanced features make it a valuable asset for managing large and complex network environments.
