Logitech Tap Scheduler - Purpose-Built Scheduling Panel for Meeting Spaces

Right Place. Right Time.
Logitech Tap Scheduler makes it simple to view meeting details, check room availability, and reserve spaces on the fly or in advance. Designed specifically for professional environments, Tap Scheduler integrates with leading room scheduling platforms to help your teams find and claim the right space—fast.

---

KEY FEATURES

Instant Availability at a Glance
Tap Scheduler features colored LED indicators that signal room status from a distance—green for available, red for booked—helping users quickly identify an open space.

Streamlined, Professional Installation
Install Tap Scheduler cleanly on any surface using included mounts for glass, mullions, or walls. Integrated cable management ensures a neat and reliable setup.

Tailored for Scheduling
With a flush-mounted 10.1" touchscreen, anti-fingerprint coating, and a wide viewing angle, Tap Scheduler is designed for clear visibility and everyday durability.

Built to Fit Any Workplace
Whether deployed in corporate conference rooms, co-working spaces, or campus environments, Tap Scheduler seamlessly adapts with robust hardware and compatibility across room systems.

Seamless Platform Integration
Certified for Microsoft Teams Panels and Zoom Rooms Scheduling Displays, and fully compatible with providers like Robin, Appspace, RICOH Spaces, Envoy, Korbyt, and Comeen.

---

TECHNICAL SPECIFICATIONS

PHYSICAL DIMENSIONS

Device Only

• Height: 6.5 in (165 mm)

• Width: 9.69 in (246.2 mm)

• Depth: 1.12 in (28.5 mm)

• Weight: 700 g (24.7 oz)

Surface-Mounted

• Depth: 1.24 in (31.4 mm)

Mullion-Mounted

• Width: 11.52 in (292.6 mm)

• Depth: 1.75 in (44.5 mm)

---

DISPLAY

• Size: 10.1” IPS touchscreen

• Resolution: 1280 x 800

• Brightness: 400 nits

• Contrast Ratio: 1000:1

• Touch: 10-point capacitive multitouch

• Anti-fingerprint: Oleophobic coating

• Viewing Angle: 85° in all directions

• Position: Flat-mount at 0° angle

---

TECHNOLOGY AND CONNECTIVITY

• Operating System: Logitech CollabOS

• Management: Logitech Sync (remote management and updates)

• Power: PoE (IEEE 802.3af Type 1, Class 3)

  • Requires PoE-enabled network or PoE injector (not included)

• Connectivity:

  • Ethernet 10/100 Mbps

  • WiFi (802.11a/b/g/n/ac/ax)

  • Bluetooth 5.0 (reserved for future use)

• Cable Routing: Horizontal / Vertical / Center Exit

• Mounting: VESA 100 x 100 mm

---

SENSORS & SECURITY

• Integrated Sensors:

  • Accelerometer

  • Ambient Light Sensor

• Data Security:

  • Full Disk Encryption (AES-128)

  • Data Encryption with Symmetric Keys & PKI

  • Hardware-based key protection (Arm TrustZone)

  • Device Identity via Hardware Attestation

---

SUSTAINABILITY

• Plastics include 54% post-consumer recycled materials (Graphite version)

---

ENVIRONMENTAL

• Operating Temp: 0 – 40°C

• Storage Temp: -40 – 70°C

• Humidity: 10–95% (non-condensing)

---

IN THE BOX

• Tap Scheduler panel

• Multi-surface mount (glass/drywall)

• Corner mount accessory

• Mullion mount

• Mounting hardware

• Documentation

---

PLATFORM COMPATIBILITY

Fully compatible with:

• Microsoft Teams Panels

• Zoom Rooms Scheduling Displays

• Robin

• Appspace

• RICOH Spaces

• Envoy

• Korbyt

• Comeen

• Logitech Room Booking Solutions
