Ubiquiti U6-Mesh Access Point

The Ubiquiti Networks U6-Mesh is designed to provide high-speed wireless connectivity with a maximum data transfer rate of 4800 Mbit/s. This Wi-Fi 6 access point supports both 2.4 GHz and 5 GHz frequency bands, delivering optimal performance across a variety of applications. With its advanced Multi-User MIMO technology, the U6-Mesh can handle multiple simultaneous connections, making it ideal for high-density environments.

Equipped with Power over Ethernet (PoE) support, this access point simplifies installation by eliminating the need for separate power cables. The U6-Mesh is built to withstand various environmental conditions with an IPX5 rating for water resistance and operates efficiently within a temperature range of -30 to 60 °C. Its sleek white design and compact dimensions make it a versatile choice for ceiling, wall, pole, or table mounting.

Key Features:

1. High-Speed Performance:

   • 4800 Mbit/s Data Transfer Rate: Achieves a maximum combined throughput of 4800 Mbit/s, with 573.5 Mbit/s on 2.4 GHz and up to 4800 Mbit/s on 5 GHz, ensuring fast and reliable wireless connectivity.

2. Advanced Wi-Fi Technology:

   • Wi-Fi 6 Support: Incorporates the latest Wi-Fi 6 technology, offering improved speed, capacity, and efficiency compared to previous standards.
   • Multi-User MIMO: Enhances network performance by allowing multiple devices to communicate with the access point simultaneously.

3. Flexible Connectivity:

   • Power over Ethernet (PoE) Support: Simplifies installation with PoE, eliminating the need for additional power cables and supporting an AC input voltage range of 44 - 57 V.

4. Robust Security:

   • Comprehensive Security Protocols: Supports WPA, WPA-Enterprise, WPA-PSK, WPA2, and WPA3 to ensure secure wireless connections.

5. Durable Design:

   • IPX5 Rating: Provides protection against water jets from any angle, making it suitable for various installation environments.
   • Temperature Range: Operates effectively within a wide temperature range of -30 to 60 °C, ensuring reliability in diverse conditions.

Specifications:

• Data Transfer Rate (Max): 4800 Mbit/s
• Maximum Data Transfer Rate (2.4 GHz): 573.5 Mbit/s
• Maximum Data Transfer Rate (5 GHz): 4800 Mbit/s
• Ethernet LAN Data Transfer Rate: 1000 Mbit/s
• Frequency Band: 2.4 - 5 GHz
• Network Standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3af
• Wiring Technology: 10/100/1000Base-T(X)
• Bluetooth: Yes
• MIMO: Yes, Multi User MIMO
• VLAN Support: Yes
• Quality of Service (QoS): Yes
• Supported Security Algorithms: WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA3
• Ethernet LAN (RJ-45) Ports: 1
• Power over Ethernet (PoE) Support: Yes
• AC Input Voltage: 44 - 57 V
• Input Current: 0.32 A
• Power Consumption (Max): 11.4 W
• Design Mounting Options: Ceiling, Pole, Table, Wall
• Color: White
• Case Material: Aluminium, Plastic
• International Protection (IP) Code: IPX5
• Reset Button: Yes
• LED Indicators: Yes
• Antenna Type: Internal
• Antenna Gain Level (Max): 5 dBi
• Operating Temperature Range: -30 to 60 °C
• Relative Operating Humidity Range: 5 - 95%
• Dimensions: Width 48.5 mm, Depth 48.5 mm, Height 159.5 mm
• Weight: 400 g
• Packaging Includes: 1 pc., PoE adapter included

Conclusion: The Ubiquiti Networks U6-Mesh access point stands out with its impressive 4800 Mbit/s data transfer rate and robust Wi-Fi 6 capabilities. Designed for both performance and durability, it ensures fast, reliable connectivity across multiple devices in various environments. Its PoE support simplifies installation, while its IPX5 rating and wide temperature range make it suitable for diverse conditions. Ideal for both residential and commercial settings, the U6-Mesh offers a powerful solution for modern networking needs.
